60W Medical Power Adapter 19V 3.16A

The 60W Medical Power Adapter is designed for OEM medical device manufacturers requiring a safe and dependable external AC/DC power supply. Delivering a stable 19V DC / 3.16A output, it provides reliable power for battery charging circuits and direct system operation in portable and stationary medical equipment.

Designed in accordance with IEC 60601-1, the adapter incorporates 2×MOPP isolation, low leakage current, and reinforced insulation to ensure patient safety in clinical environments.

With universal 90–264VAC input, high conversion efficiency, and a compact enclosure, this medical-grade adapter is suitable for worldwide deployment across hospitals, laboratories, and healthcare facilities.

The output cable, DC connector, AC inlet, labeling, and regional safety approvals can all be customized for OEM and ODM projects.

IEC/EN 60601 Medical Safety

Low Leakage Current

Compact & Lightweight

High Effficiency

The 60W Medical Power Adapter delivers a regulated 19V DC output at 3.16A for medical and healthcare equipment requiring safe, reliable external power. Designed to comply with IEC 60601-1 medical safety standards, it features low leakage current, high efficiency, and 2×MOPP isolation, making it ideal for portable medical devices, diagnostic equipment, medical displays, and patient monitoring systems.

Technical Specification

Input Connector/Plug Type

C14

Output Connector

BARREL CONNECTOR

Rated Power

60W

Output Voltage

19V

Output Current

3.16

Model

XJKMD60W-190316

Safety Standards

IEC/EN 60601
Download Datasheet
Request a Quote

Typical Applications

Portable Patient Monitor

Provides stable external power and supports battery charging for portable multi-parameter monitoring systems.
Learn More→

Medical Display

Delivers clean DC power for diagnostic displays used in hospitals and imaging systems.
Learn More→

Portable Ultrasound System

Supports compact ultrasound equipment requiring efficient and reliable medical-grade power.
Learn More→

Diagnostic Medical Equipment

Suitable for portable diagnostic devices requiring IEC 60601-1 compliant external power supplies.
Learn More→

Key Engineering Features

IEC 60601-1 Certified

Designed for medical electrical equipment requiring international medical safety compliance.

2×MOPP Isolation

Provides reinforced patient protection between AC input and DC output.

Low Leakage Current

Suitable for patient-connected medical devices requiring enhanced electrical safety.

Stable 19V DC Output

Regulated 19V / 3.16A output ensures reliable performance for medical electronics and battery charging circuits.

High Energy Efficiency

Low standby power consumption and reduced heat generation improve overall system reliability.

OEM & ODM Customization

Support for customized output voltage, DC connector, cable length, housing, and regional certifications.

Electrical Performance

Parameter Specification
Rated Power 60W
Input Voltage 90–264VAC
Input Frequency 47–63Hz
Output Voltage 19V DC
Output Current 3.16A
Output Power 60W Max
Efficiency DOE Level VI
Ripple & Noise Low Ripple Design
Leakage Current IEC 60601-1 Compliant
Protection OVP / OCP / SCP
Isolation 2×MOPP
Operating Temperature 0°C to +40°C (Typical)
Safety Standards IEC 60601-1
EMC Standards IEC 60601-1-2
MTBF High Reliability Design
Connector Custom Available

Why This Adapter Fits Medical Devices

Low Leakage Current Design

Designed to keep patient leakage current within IEC 60601-1 safety limits for medical applications.

Stable Output Performance

Provides tightly regulated DC output with minimal voltage fluctuation under varying load conditions.

Compact for Portable Devices

Compact enclosure design optimized for integration into portable and space-constrained medical equipment.

IEC 60601 Compliance

Complies with IEC/EN 60601-1 safety standards for medical electrical equipment, including 2×MOPP isolation requirements.

Certifications

  • IEC/EN 60601-1 & 60601-2
  • CE(Europe)/UL/CB/UKCA
  • RoHS Compliance
  • DOE Level VI

Engineering Resources

FAQ

Is this adapter certified to IEC 60601-1?

Yes. It is designed to comply with IEC 60601-1 medical safety requirements and provides 2×MOPP isolation for patient protection.

Can this adapter charge an internal battery?

Yes. The adapter provides stable DC output for battery charging circuits integrated into portable medical devices.

Is 19V the only available output?

No. Customized output voltages are available according to OEM project requirements.

Can the DC connector be customized?

Yes. Multiple DC plug types, cable lengths, and connector options are supported.

Does it support worldwide AC input?

Yes. The adapter accepts 90–264VAC input for global applications.

Which medical devices commonly use this adapter?

It is commonly used in portable patient monitors, medical displays, portable ultrasound systems, diagnostic equipment, and other IEC 60601-1 compliant medical devices.
